Compound Semiconductors

Dedicated inspection and metrology solutions addressing unique processes

Compound semiconductors are undergoing a major expansion addressing many new applications and using various materials such as SiC, GaN, GaAs and others, to improve the performance of new devices in several segments such as Power, LIDAR and Face Recognition.

The compound semiconductors manufacturing process is unique and requires dedicated solutions for Inspection and Metrology. Camtek’s offering includes the inspection of Epitaxial layers, inner cracks within the Epitaxial layer, surface topography, Bow measurement, data analysis and more.

Capabilities

  • Small defect detection at high resolution
  • Inspection of transparent wafers
  • Metrology, including wafer bow measurement, surface topography
  • Inspection – epitaxial substrate
  • Line process
  • Data analysis
  • Yield prediction

Technologies

Products

Eagleᵀ-AP Plus

Industry standard

Learn More >

Eagle G5

the Eagle G5 is engineered to deliver unmatched speed and efficiency

Learn More >

Eagleᵀ-i Plus

Superior detection

Learn More >
